PIC32MM MCU 系列
Microchip 推出其采用小封装的 32 位、低成本 PIC32MM MCU 系列（PIC32MM MCU Family）
发布时间：2018-06-14
Microchip 的 PIC32MM MCU 系列填补了该公司广受欢迎的 PIC24F XLP 和 PIC32MX 系列之间的空白。该系列是首款采用内核独立外设的 PIC32 器件，旨在减轻 CPU 负载，以实现更低的功耗和更低的系统成本。这些 PIC32MM 器件受 Microchip MPLAB 代码配置器 (MCC) 支持，可帮助简化并加快设计。
PIC32MM MCU 系列特性
低成本
低功耗模式
休眠模式 5 μA
低电压休眠模式 500 nA
低功耗休眠模式，优化了多数时间处于休眠模式的电池应用的功耗
小型封装
4 mm x 4 mm - 20 QFN, 28 µQFN
5 mm x 5 mm - 40 µQFN
6 mm x 6 mm - 28 QFN, 36 QFN
小至 4 mm x 4 mm，适合空间受限型应用
外设集成
外设丰富，小引脚数封装
两个 UART、两个 SPI、两个 SCCP、一个 MCCP、七个定时器、PPS 和两个 CLC
14 通道 x 12 位 200 ksps ADC，两个比较器
PIC32MM MCU 系列应用
一、低功耗和无线应用
IoT 传感器节点
联网温控器
环境监测
遥控器
便携式医疗设备
二、消费类
游戏机
家庭护理设备
健身设备
三、低成本电机控制
白色家电
桌面电器
四、工业控制应用
楼宇自动化
加热控制
照明控制
| 图片 | 数据手册 | 产品型号 | 产品分类 | 产品描述 | 价格 | 操作 |
|---|---|---|---|---|---|---|
 | | DM320101 | 8位MCU单片机-单片机/ARM/DSP | ￥174.47811 | 在线订购 | |
 | | MA320020 | 开发板/套件/编程器配件-开发板/套件/编程器 | PIC32MM0064GPL036GENERALPURPOS | ￥218.27737 | 在线订购 |
| 图片 | 数据手册 | 产品型号 | 产品分类 | 产品描述 | 价格 | 操作 |
|---|---|---|---|---|---|---|
 | | PIC32MM0064GPL036-I/MV | 其它微处理器-单片机/ARM/DSP | ￥18.82246 | 在线订购 | |
 | | PIC32MM0064GPL036-I/M2 | 其它微处理器-单片机/ARM/DSP | The PIC32MM family is Microchip's lowest power and most cost-effective family of 32-bit PIC32 microcontrollers. ?For applications demanding low power, longer battery life and space?constraints, the PIC32MM devices offer sleep modes down?to 500 nA and packages as small as 4 × 4 mm.This family?features core independent peripherals, designed to offload?the CPU, such as Configurable Logic Cells (CLC) and?Multiple-output Capture Compare PWMs (MCCPs) which?help enable sensorless BLDC motor control applications.?The PIC32MM devices achieve a 79 CoreMark score?at 25 MHz operation, featuring the compact microMIPS?instructions, microAptiv UC core and a shadow register?set for fast interrupt context switching. The microMIPS ISA?combines 16-bit and 32-bit instructions for compact code?size.The PIC32MM GPL devices are supported by Microchip’s?MPLAB Code Configurator (MCC) to help simplify designs. ?Target applications include IoT sensor nodes, connected thermostats, environmental monitoring devices, portable medical or fitness devices, building automation and low cost motor control applications. | ￥19.00764 | 在线订购 |
 | | PIC32MM0016GPL028-I/M6 | 其它微处理器-单片机/ARM/DSP | The PIC32MM family is Microchip's lowest power and most cost-effective family of 32-bit PIC32 microcontrollers. ?For applications demanding low power, longer battery life and space?constraints, the PIC32MM devices offer sleep modes down?to 500 nA and packages as small as 4 × 4 mm.This family?features core independent peripherals, designed to offload?the CPU, such as Configurable Logic Cells (CLC) and?Multiple-output Capture Compare PWMs (MCCPs) which?help enable sensorless BLDC motor control applications.?The PIC32MM devices achieve a 79 CoreMark score?at 25 MHz operation, featuring the compact microMIPS?instructions, microAptiv UC core and a shadow register?set for fast interrupt context switching. The microMIPS ISA?combines 16-bit and 32-bit instructions for compact code?size.The PIC32MM devices are supported by Microchip’s?MPLAB Code Configurator (MCC) to help simplify designs. ?Target applications include IoT sensor nodes, connected thermostats, environmental monitoring devices, portable medical or fitness devices, building automation and low cost motor control applications. | 在线订购 | |
 | | PIC32MM0016GPL036-I/M2 | 其它微处理器-单片机/ARM/DSP | The PIC32MM family is Microchip's lowest power and most cost-effective family of 32-bit PIC32 microcontrollers. ?For applications demanding low power, longer battery life and space?constraints, the PIC32MM devices offer sleep modes down?to 500 nA and packages as small as 4 × 4 mm.This family?features core independent peripherals, designed to offload?the CPU, such as Configurable Logic Cells (CLC) and?Multiple-output Capture Compare PWMs (MCCPs) which?help enable sensorless BLDC motor control applications.?The PIC32MM devices achieve a 79 CoreMark score?at 25 MHz operation, featuring the compact microMIPS?instructions, microAptiv UC core and a shadow register?set for fast interrupt context switching. The microMIPS ISA?combines 16-bit and 32-bit instructions for compact code?size.The PIC32MM GPL devices are supported by Microchip’s?MPLAB Code Configurator (MCC) to help simplify designs. ?Target applications include IoT sensor nodes, connected thermostats, environmental monitoring devices, portable medical or fitness devices, building automation and low cost motor control applications. | 在线订购 | |
| | PIC32MM0032GPL036-I/M2 | 其它微处理器-单片机/ARM/DSP | The PIC32MM family is Microchip's lowest power and most cost-effective family of 32-bit PIC32 microcontrollers. ?For applications demanding low power, longer battery life and space?constraints, the PIC32MM devices offer sleep modes down?to 500 nA and packages as small as 4 × 4 mm.This family?features core independent peripherals, designed to offload?the CPU, such as Configurable Logic Cells (CLC) and?Multiple-output Capture Compare PWMs (MCCPs) which?help enable sensorless BLDC motor control applications.?The PIC32MM devices achieve a 79 CoreMark score?at 25 MHz operation, featuring the compact microMIPS?instructions, microAptiv UC core and a shadow register?set for fast interrupt context switching. The microMIPS ISA?combines 16-bit and 32-bit instructions for compact code?size.The PIC32MM GPL devices are supported by Microchip’s?MPLAB Code Configurator (MCC) to help simplify designs. ?Target applications include IoT sensor nodes, connected thermostats, environmental monitoring devices, portable medical or fitness devices, building automation and low cost motor control applications. | 在线订购 |
